inLOOP systems have been designed for use in applications where exceptional sound reproduction and signal clarity is imperative. Two generations beyond constant current technology, inLOOP systems are powered by our exclusive state of the art Digital High Efficiency Audio Frequency Induction Amplifier. This leap in technology makes inLOOP uniquely qualified to produce the best quality loop signal in the industry. inLOOP systems provide a more consistent hearing loop field with lower energy consumption and low operating temperatures. This HD system is designed to work with phased array loop antennas up to 6,000 sq. ft. or with two separate outputs for areas of 3000 sq ft or less.
Specifications
Power requirements - 100 - 240 volts AC ~ 50/60Hz 3.5 amps
Coverage - IEC 60118-4 compliant as tested at 6000 sq ft with connected metal in 50% of the loop field
Loop output as tested above - 4 amps RMS x 2
12 volts RMS
Inputs - 2 combination 1/4 XLR jacks. Switchable microphone and phantom power selectors.
Controls - 2 Individual input volume controls with indicator lights.
Metal Loss (Treble) control
Loop Output control
Power switch with an indicator light
Built in Phase Shifter
Dimensions - 19’ x 8 1/2” x 1 3/4” Standard 19” rack 1RU
Weight - 6 lbs
Power Supply Approvals - UL ULC CE
Made in the USA
Limited Lifetime Warranty
Commercial HD Brochure
Only for sale to qualified installers, please contact us for current pricing.
